Engine for tiller / cultivator Loncin G200F-B 6.5 HP (with reducer 2:1)
Our benefits
Description
This 6.5 HP engine is compatible with some models of tillers or cultivators.
It is suitable for certain applications such as chainsaws, tillers, go-karts, etc., where a 2:1 speed reduction is necessary.
The presented product benefits from a guarantee according to Law no. 449/2003 ONLY IF IT IS MOUNTED IN A SPECIALIZED SERVICE!!
If the product is self-assembled, it NO LONGER BENEFITS FROM THE WARRANTY!!
Failure to comply with the service schedule will void the warranty!
Any operation performed on the engine will be done in a specialized workshop!
Failure to complete the table / incorrect completion leads to cancellation of the warranty.
Manual:
Technical specifications:
Cylinder capacity: 196cc
Bore x Stroke (mm): 68 x 54
Maximum speed (n.m)/rpm] : 1.35(13.2)/2500
Ignition: Electronics
Spark plug type: BPR6ES / RN9YC / W7DCR
Starting Pull (with starter)
Petrol tank capacity: 3.6L
Oil bath capacity: 0.6L
Consumption: 230g/hp.h (313g/kw.h)
Air filter: Dry
Shaft length (extruding part): 50mm
Clutch Centrifugal clutch
Package dimensions: 530 x 450 x 500 mm
Weight 19.3kg
Direction of rotation: Counter-clockwise
The diameter of the reducer shaft 20mm
Motor shaft diameter 20mm
Reducer 2-1
